We are passionate experienced team with big ambitions.
Fuel System:
● Fuel pump Bosch 0404 6 bar. ● Injectors bosch 980cc● Fuel piping FTF ● FTF fuel filter ● Fuel cell 70 liters on rear axle ● FTF fuel pressure regulator
Suspension:
● New shocks at rear ACL. ● Rear diff support removed, installed 6mm diff supports ● Strut brace link suspension built for antiroll on diff ● Rose joint links to rear ACL build for drag and antiroll rear suspension. ● 30mm link arms to cabin supports fitted to leave springs ● Strut brace for front shocks support.
Fuel System:
● Fuel pump Bosch 0404 6 bar. ● Injectors bosch 980cc● Fuel piping FTF ● FTF fuel filter ● Fuel cell 70 liters on rear axle ● FTF fuel pressure regulator
Suspension:
● New shocks at rear ACL. ● Rear diff support removed, installed 6mm diff supports ● Strut brace link suspension built for antiroll on diff ● Rose joint links to rear ACL build for drag and antiroll rear suspension. ● 30mm link arms to cabin supports fitted to leave springs ● Strut brace for front shocks support.
Specs: Custom build
Engine:
● Built for 2 bar boost. ● Twin cam Supercharge engine
● Small port Head configuration ● Head, valves, guides, valves seals are all
re-done. ● CP Forged Pistons Toyota 4AG 81.5mm ● Conrods max speed rods with
ARP2000 studs ● ARP head bolts ● ARP main bolt ● ARP big end bolts ● Cometic
head gasket ● Main bearings ACL ● Big end bearings ACL ● Oil pump upgrade ACL ●
Only done 17km startup on new build running in ● Bosch alternator 70amp ● No
distributor running 30-2crank pickup ● Audi R8 coil ● Engine Oil still mono grade for running in ● Before
engine forged done 193kw/300nm/0.9bar boost/ pump fuel ● Gates cambelt blue
type ● Vernier cam pulley's ● No Silicone used on engine build all gaskets are
cut out for applications
Fuel System:
● Fuel pump Bosch 0404 6 bar. ● Injectors bosch 980cc● Fuel piping FTF ● FTF fuel filter ● Fuel cell 70 liters on rear axle ● FTF fuel pressure regulator
Brake System:
● FNew brake booster. ● New master cylinder ● Brake lines FTF
Gearbox:
● Toyota R21 gearbox. ● 50/50 ration gearbox oil and ATF.
Electrical:
● All motor wiring separater. ● All automotive sleeving done on wiring ● Duel battery system new cable 35# to engine components ● Separate relay and fuse system for engine components.
Suspension:
● New shocks at rear ACL. ● Rear diff support removed, installed 6mm diff supports ● Strut brace link suspension built for antiroll on diff ● Rose joint links to rear ACL build for drag and antiroll rear suspension. ● 30mm link arms to cabin supports fitted to leave springs ● Strut brace for front shocks support.
Diff:
● Diff modification with Cressida internals.
ECU:
● EFI Analytics software platform● Oil protection.● Fuel protection ● Engine rpm protection ● Auto tune capability.● Run in tune currently loaded for 1000km. ● Live AFR Aim Lambda with gauge display ● Boost tune to be loaded after engine run in ● ECU capable running flex fuel close loop for fuel mix E85 or E50 high boost ● Engine protection for oil and fuel and cold conditions RPM limiter activated ● No acceleration is possible before engine is constantly above 40 degrees for new engine.
