DIAGNOSTIC

In most instances, a diagnostic test can be swiftly conducted, typically within minutes. However, not everyone is well-versed in the specifics of such a diagnostic procedure. This machine will interface with your vehicle's computer processor, sensors, and microchips. The diagnostic test will provide comprehensive insights into your vehicle's engine health, including details on ignition timing, engine deposits, fuel injector performance, ignition coil functionality, engine RPM, ambient temperatures, airflow, crankshaft and camshaft positions, throttle operation, transmission status, exhaust system condition, and brake performance. Through this diagnostic process, we can precisely identify any areas of concern that may necessitate attention.

Description of standardized OBD trouble codes by category family

Standard or generic fault codes encompass a set of codes universal across all manufacturers.

Known as Data Trouble Codes (DTC), this list of faults has been established to enable any diagnostic tool to interpret and decipher them. These codes adhere to a uniform format illustrated below

Copy_of_Car_Wash___Auto_Detailing_Flyer__1_-removebg-preview (1)

The classification of Diagnostic Trouble Codes (DTC) is structured as follows:

The initial letter designates the DTC family:

P: Powertrain (comprising the engine and gearbox)

C: Chassis

B: Body

U: User network


The first digit distinguishes between generic and manufacturer-specific codes (highlighted in green):

0: Generic fault

1: Manufacturer-specific fault


Manufacturers have the flexibility to supplement the standard OBD codes with proprietary codes as needed.

The last three digits represent a sequential number (indicated in red).

In some cases, these digits may be hexadecimal (ranging from 0 to 9 and A to F). Within the P family codes, subcategories are defined based on the first digit, as exemplified by the following breakdown:


0, 1, and 2: related to the air/fuel mixture

3: associated with the ignition system

4: involved in auxiliary emissions monitoring

5: pertaining to engine idling

6: concerning the onboard computer and ancillary outputs

7, 8, and 9: dealing with transmission (gearbox) issues

A, B, and C: specific to hybrid propulsion


These OBD codes adhere to the standards set by SAE J2012 and ISO 15031-6, encompassing approximately 11,000 defined codes in the latest versions available.
